The ONSemi RURG3060CC is an ultrafast dual rectifier diode. It features a fast reverse recovery time of 60 nanoseconds at a forward current of 30A, a low forward voltage drop of 1.5 volts at 25°C, and a high reverse voltage rating of 600V. It's suitable for high - frequency switching power supplies and various power - switching applications, offering high efficiency and reliability.
ONSemi RURG3060CC's Features
ONSemi's RURG3060CC is an excellent-performance ultrafast dual diode with numerous practical features. Its reverse recovery time is extremely fast. When the forward current is 30A, it is only 60 nanoseconds. This characteristic enables it to respond rapidly to current changes in high-frequency switching power supplies and other power switching applications, significantly reducing switching losses and enhancing the system efficiency.
The forward voltage drop is relatively low. At 25°C, the maximum forward voltage is 1.5 volts. A lower forward voltage drop means that the energy loss is smaller when the current is conducting, which helps to improve the overall performance of the power supply. This diode also has the ability to withstand a reverse voltage of 600 volts, with high reliability, and it can operate stably in a high-voltage environment. In addition, it has an avalanche energy rating, which can effectively deal with abnormal situations such as avalanche breakdown. Moreover, the RURG3060CC complies with the lead-free and RoHS standards, meeting the environmental protection requirements. In the modern electronic field that pursues green environmental protection, it can be widely applied to various circuit designs with strict environmental protection requirements.
ONSemi RURG3060CC's Applications
ONSemi's RURG3060CC ultrafast dual diode has a wide range of applications. In switching power supplies, it is a key component. As a freewheeling diode, when there is a sudden change in the inductor current in the circuit, it can provide a current release path, preventing other devices from being damaged by the back electromotive force generated by the inductor and ensuring the stable operation of the power supply. At the same time, it can also act as a clamping diode, limiting the voltage within a safe range and protecting the sensitive components in the circuit.
In terms of industrial applications, the RURG3060CC can be used in various power conversion circuits. Its extremely fast recovery time and low forward voltage drop enable it to effectively reduce energy consumption during frequent switching operations, improving the efficiency and reliability of the system. For example, in a motor drive circuit, it can help the motor start and run smoothly, reducing power waste.
It also plays an important role in general power switching circuits. With its ability to withstand a reverse voltage of 600V and high reliability, it is capable of handling both small electronic devices and large power systems. It ensures that the circuit operates normally under different working conditions, providing stable and efficient power support for various circuits.
ONSemi RURG3060CC's Attributes
| Product Category |
Diodes - General Purpose, Power, Switching |
RoHS |
Details |
| REACH |
Details |
Product |
Switching Diodes |
| Mounting Style |
Through Hole |
Package / Case |
TO-247 |
| Peak Reverse Voltage |
600 V |
Max Surge Current |
325 A |
| If - Forward Current |
30 A |
Configuration |
Dual |
| Recovery Time |
60 ns |
Vf - Forward Voltage |
1.5 V |
| Ir - Reverse Current |
250 uA |
Minimum Operating Temperature |
- 65 C |
| Maximum Operating Temperature |
+ 175 C |
Series |
RURG3060CC |
| Brand |
onsemi / Fairchild |
Height |
20.82 mm |
| Length |
15.87 mm |
Product Type |
Diodes - General Purpose, Power, Switching |
| Factory Pack Quantity |
450 |
Subcategory |
Diodes & Rectifiers |
| Termination Style |
Through Hole |
Type |
Switching Diode |
| Vr - Reverse Voltage |
600 V |
Width |
4.82 mm |
| Part # Aliases |
RURG3060CC_NL |
Unit Weight |
0.225401 oz |
ONSemi RURG3060CC's Category- Rectifier Diodes
Rectifier Diode, as its name implies, is a diode used to rectify alternating current of commercial frequency. In the modern power electronics field, converting alternating current into direct current is an extremely crucial step, and the rectifier diode is the core component that realizes this conversion. It has remarkable characteristics of high voltage and high current, and can withstand large voltage and current loads, thus ensuring stable operation in various complex power environments.
In addition, the performance of rectifier diodes varies depending on the operating frequency and conditions. To meet the diverse market demands, a variety of rectifier diode products have emerged on the market. Among them, there are products with low VF (forward voltage) characteristics. When these diodes are conducting, the forward voltage drop is small, which can effectively reduce power consumption and improve energy efficiency. High - speed switching products, with their fast switching speed, can respond rapidly in high - frequency circuits to achieve efficient current conversion. There are also low - noise products that can reduce electromagnetic interference during operation and provide a stable power supply for noise - sensitive electronic devices.
Among numerous rectifier diode products, the ONSemi RURG3060CC stands out. As an ultrafast dual diode, it has an extremely fast reverse recovery time. When the forward current is 30A, it is only 60 nanoseconds. This feature enables it to respond quickly to current changes in applications such as high - frequency switching power supplies, greatly reducing switching losses. Its forward voltage drop is low, with a maximum forward voltage of 1.5 volts at 25°C, effectively reducing energy losses during conduction. Moreover, it has the ability to withstand a reverse voltage of 600 volts, high reliability, and an avalanche energy rating, which can effectively deal with abnormal situations. Not only that, it complies with lead - free and RoHS standards, showing excellent environmental performance. Whether it is in switching power supplies, industrial applications, or general power switching circuits, the ONSemi RURG3060CC can rely on its outstanding performance to provide you with a stable, efficient, and environmentally friendly solution for circuit design.
Wls Electronic has a large inventory of onsemi RURG3060CC. We guarantee that they are original and brand - new parts purchased directly from onsemi. We can provide quality test reports for RURG3060CC according to your requirements. To get a quotation, simply fill in the required quantity, contact name, and email address in the quick quotation form on the right - hand side. Our sales representatives will contact you within 12 hours. You can contact us online at any time or send us an email: SALES@WLSCHIP.COM.
