Analog Devices AD7606BSTZ Analog to Digital Converters

Update time : 2025-04-21 14:18:28

The Analog Devices AD7606BSTZ is an 8 - channel, 16 - bit data acquisition system. It can handle true bipolar analog input signals with ranges of ±10 V or ±5 V. Operating on a single 5 V analog supply and 2.3 V - 5 V VDRIVE, it offers a fully integrated solution. It features an input buffer with 1 MΩ impedance, a second - order antialiasing filter, and an on - chip reference. The ADC has a 200 kSPS throughput rate and oversampling capability. With a flexible parallel/serial interface, it's compatible with various standards. Ideal for applications like power - line monitoring and motor control, it combines high - performance and versatility.

Analog Devices AD7606BSTZ's Features

The Analog Devices AD7606BSTZ is a high - performance data acquisition device with multiple notable features. It offers 8 simultaneously sampled inputs, enabling it to capture multiple analog signals at the same time. The device has true bipolar analog input ranges of ±10 V and ±5 V, which is suitable for a wide range of applications dealing with bipolar signals. It is pin - to - pin compatible with the state - of - the - art AD7606B, facilitating easy replacement or upgrade in existing designs. Operating from a single 5 V analog supply and 2.3 V to 5 V VDRIVE, it provides a fully integrated data acquisition solution. It includes analog input clamp protection, an input buffer with 1 MΩ analog input impedance, a second - order antialiasing analog filter, and an on - chip accurate reference and reference buffer. The 16 - bit ADC can operate at a throughput rate of 200 kSPS on all channels and has oversampling capability with a digital filter. It also features a flexible parallel/serial interface that is SPI/QSPI/MICROWIRE/DSP compatible. Additionally, it has a 7 kV ESD rating on analog input channels, high SNR (up to 95.5 dB), and low power consumption, making it ideal for various applications like power - line monitoring and motor control.

Analog Devices AD7606BSTZ's Applications

The Analog Devices AD7606BSTZ is a versatile 16 - bit data acquisition system with multiple applications across various industries. In power - line monitoring and protection systems, its ability to simultaneously sample multiple channels and handle bipolar input signals is crucial. It can accurately measure parameters such as voltage and current in power lines. With its high - speed conversion rate of 200 kSPS and wide input range (±10 V or ±5 V), it can quickly detect any abnormalities in the power grid, enabling timely protection measures to prevent equipment damage. For multiphase motor control, the AD7606BSTZ helps in precisely monitoring motor currents and voltages. The simultaneous sampling feature ensures accurate phase - current measurement, which is essential for efficient motor operation. By providing high - resolution data (16 - bit), it enables better control algorithms, improving motor performance, reducing energy consumption, and enhancing reliability. In instrumentation and control systems, this device is used to gather data from multiple sensors. Its on - chip antialiasing filter and high - impedance input buffer make it suitable for interfacing with a variety of sensors. The flexible digital filter and high SNR (up to 95.5 dB) contribute to accurate data acquisition, facilitating reliable control and measurement in industrial and scientific equipment.

Analog Devices AD7606BSTZ's Attributes

Product Category	Analog to Digital Converters - ADC	RoHS	Details
Series	AD7606	Mounting Style	SMD/SMT
Package / Case	LQFP-64	Resolution	16 bit
Number of Channels	8 Channel	Interface Type	Parallel, SPI
Sampling Rate	200 kS/s	Input Type	Single-Ended
Architecture	SAR	SNR - Signal to Noise Ratio	95.5 dB
Minimum Operating Temperature	- 40 C	Maximum Operating Temperature	+ 85 C
Brand	Analog Devices	Development Kit	EVAL-AD7606EDZ
DNL - Differential Nonlinearity	+/- 0.99 LSB	Gain Error	+/- 32 LSB
Height	1.4 mm	INL - Integral Nonlinearity	+/- 2 LSB
Input Voltage	+/- 5 V/+/- 10 V	Length	10 mm
Moisture Sensitive	Yes	Number of ADC Inputs	8 Input
Number of Converters	1 Converter	Operating Supply Voltage	5 V
Pd - Power Dissipation	142 mW	Power Consumption	100 mW
Product Type	ADCs - Analog to Digital Converters	Reference Type	External, Internal
Sample and Hold	Yes	Factory Pack Quantity	160
Subcategory	Data Converter ICs	Supply Voltage - Max	5 V
Supply Voltage - Min	5 V	Type	S/H ADC
Width	10 mm	Unit Weight	0.028219 oz

Analog Devices AD7606BSTZ's Datasheet

Analog Devices AD7606BSTZ's Category-Analog to Digital Converters

Analog - to - Digital Converters (ADCs) play a pivotal role in modern electronics by enabling communication between the real - world, which is characterized by continuous analog signals, and digital systems. Analog signals, sourced from various sensors such as those measuring temperature, light, sound, or movement, exhibit continuously varying values. In contrast, digital electronic circuits operate on binary signals with only two discrete states: logic “1” (HIGH) and logic “0” (LOW). The core function of an ADC is to take a snapshot of an analog voltage at a specific instant and transform it into a digital output code that represents that voltage. The resolution of an ADC, determined by the number of binary digits (bits) used, dictates the accuracy of this conversion. For example, a 4 - bit ADC has a resolution of one part in 15 (2⁴−1), while an 8 - bit ADC offers a resolution of one part in 255 (2⁸−1). Higher - bit ADCs can represent a more extensive range of analog values with greater precision. One common type of ADC is the parallel or “flash” converter. It uses a series of comparators to simultaneously compare the input analog voltage against multiple reference voltage levels generated by a precision resistor network. The number of comparators required is 2ⁿ−1, where n is the number of output bits. Flash ADCs are known for their high - speed conversion capabilities as they do not rely on a timing clock; the conversion occurs as soon as the analog voltage is applied. However, they become more complex and costly as the resolution increases due to the large number of comparators needed.

In practical applications, high - performance ADCs are essential. This is where the Analog Devices AD7606BSTZC excels. It is an 8 - channel, 16 - bit ADC that can handle true bipolar analog input ranges of ±10 V and ±5 V. With a high throughput rate of 200 kSPS on all channels, it enables rapid and accurate data acquisition. Its integrated features, including an input buffer with 1 MΩ impedance, a second - order antialiasing filter, and an on - chip reference, make it a versatile solution for applications such as power - line monitoring, motor control, and industrial instrumentation. The AD7606BSTZC combines the fundamental principles of ADC operation with advanced features, making it a preferred choice for designers who need to bridge the gap between the analog and digital domains with high precision and reliability.

Parameter comparison of AD7606BSTZ and AD7606BSTZ-RL


Pictures	AD7606BSTZ +BOM	AD7606BSTZ-RL +BOM
Pbfree Code	Yes	No
Rohs Code	Yes	Yes
Part Life Cycle Code	Active	Active
Ihs Manufacturer	ROCHESTER ELECTRONICS INC	ANALOG DEVICES INC
Part Package Code	QFP	QFP
Package Description	LFQFP,	LQFP-64
Pin Count	64	64
Reach Compliance Code	unknown	compliant
Analog Input Voltage-Max	10 V	10 V
Analog Input Voltage-Min	-10 V	-10 V
Conversion Time-Max	4 µs	4 µs
Converter Type	ADC, PROPRIETARY METHOD	ADC, PROPRIETARY METHOD
JESD-30 Code	S-PQFP-G64	S-PQFP-G64
JESD-609 Code	e3	e3
Length	10 mm	10 mm
Linearity Error-Max (EL)	0.0031%	0.0031%
Moisture Sensitivity Level	NOT APPLICABLE	3
Number of Analog In Channels	8	8
Number of Bits	16	16
Number of Functions	1	1
Number of Terminals	64	64
Operating Temperature-Max	85 °C	85 °C
Operating Temperature-Min	-40 °C	-40 °C
Output Bit Code	2'S COMPLEMENT BINARY	2'S COMPLEMENT BINARY
Output Format	SERIAL, PARALLEL, WORD	SERIAL, PARALLEL, WORD
Package Body Material	PLASTIC/EPOXY	PLASTIC/EPOXY
Package Code	LFQFP	LFQFP
Package Shape	SQUARE	SQUARE
Package Style	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH
Peak Reflow Temperature (Cel)	260	260
Sample Rate	0.2 MHz	0.2 MHz
Sample and Hold / Track and Hold	TRACK	TRACK
Seated Height-Max	1.6 mm	1.6 mm
Supply Voltage-Nom	5 V	5 V
Surface Mount	YES	YES
Technology	BIPOLAR	BIPOLAR
Temperature Grade	INDUSTRIAL	INDUSTRIAL
Terminal Finish	MATTE TIN	Matte Tin (Sn)
Terminal Form	GULL WING	GULL WING
Terminal Pitch	0.5 mm	0.5 mm
Terminal Position	QUAD	QUAD
Time@Peak Reflow Temperature-Max (s)	40	30
Width	10 mm	10 mm
Base Number Matches	2	1
Manufacturer Package Code		ST-64-2
ECCN Code		EAR99
HTS Code		8542.39.00.01
Samacsys Manufacturer		Analog Devices
Package Equivalence Code		QFP64,.47SQ,20
Qualification Status		Not Qualified

WlS Electronic has a vast inventory of Analog Devices AD7606BSTZ. We assure you that these are genuine and brand - new components procured directly from Analog Devices. Should you need it, we are able to offer quality test reports for AD7606BSTZ. If you wish to obtain a quotation, all you need to do is fill in the required quantity, your contact name, and your email address in the quick quotation form on the right - hand side. Our sales representatives are committed to getting in touch with you within 12 hours. You have the option to contact us online at any time. Additionally, you can send us an email at: SALES@WLSCHIP.COM.
