EP2C5T144C8N Intel / Altera -FPGAs

Update time : 2025-04-23 14:40:21

The Intel/Altera EP2C5T144C8N is a versatile FPGA from the Cyclone II family. With 4,608 logic elements, it enables efficient implementation of complex digital designs. Operating at up to 260 MHz, it offers high - speed performance. Housed in a 144 - pin TQFP package, it provides ample I/O connectivity. Ideal for industrial automation, communication systems, and consumer electronics, its reliable operation across - 40°C to +85°C makes it a popular choice for various applications.

Intel / Altera EP2C5T144C8N's Features
1. Logic Resources
It offers 4608 logic elements, providing ample resources for implementing complex digital logic designs. These elements can be configured to create various functions, from simple combinational circuits to elaborate sequential logic systems.
2. High - Speed Performance
With a maximum frequency of up to 260 MHz, it enables fast - paced operation. This high - speed capability makes it suitable for applications that demand quick data processing and high - frequency signal handling, such as high - speed data communication systems.
3. Package and Pin - Count
Housed in a 144 - pin TQFP (Thin Quad Flat Package), it strikes a balance between compactness and the number of available I/O pins. The 89 available I/O lines allow for extensive connectivity to external components, facilitating seamless integration into larger systems.
4. Power - Related Features
Operating at 1.2V, it is designed with power - efficiency in mind. Moreover, its compliance with RoHS (Restriction of Hazardous Substances) standards reflects an environmentally - friendly design approach.
5. Temperature and Reliability
It can operate within a temperature range from - 40°C to + 85°C, ensuring reliable performance in a variety of environmental conditions. This wide operating temperature range makes it applicable in both industrial and consumer - grade applications where temperature variations may occur.

Intel / Altera EP2C5T144C8N's Applications

1. Industrial Automation

In industrial automation, it plays a crucial role. It can be used to control and monitor various industrial processes. For example, in robotic arms, it precisely manages the movement and positioning by processing sensor data and sending appropriate control signals. It enables real - time adjustments, enhancing the accuracy and efficiency of manufacturing operations. In conveyor belt systems, it synchronizes the speed and movement of different components, ensuring seamless material transfer and minimizing production delays.

2. Communication Systems

In the realm of communication, this FPGA is highly valuable. It can be employed in base stations to handle signal processing tasks such as modulation and demodulation. It helps in optimizing the transmission and reception of data, improving the overall communication quality. In wireless local area networks (WLANs), it manages data packet processing, ensuring fast and reliable data transfer between devices.

3. Consumer Electronics

In consumer electronics, the EP2C5T144C8N is utilized in smart TVs and set - top boxes. It processes video and audio signals, enabling high - definition playback and enhancing the user experience. In gaming consoles, it contributes to the smooth running of complex graphics and interactive gameplay by handling the computational tasks required for rendering and user input processing.

4. Medical Equipment

In the medical field, it is used in devices like electrocardiogram (ECG) machines. It accurately processes the electrical signals from the human body, converting them into interpretable data for medical professionals. In ultrasound machines, it helps in image processing, improving the clarity and precision of the scanned images, which is crucial for accurate diagnosis.

Intel / Altera EP2C5T144C8N's Attributes

EU RoHS

Compliant

ECCN (US)

EAR99

Part Status

Active

HTS

COMPONENTS

Family Name

Cyclone® II

User I/Os

Process Technology

90nm

Number of I/O Banks

Shift Registers

Utilize Memory

Operating Supply Voltage (V)

1.2

Logic Elements

4608

Number of Multipliers

13 (18x18)

Program Memory Type

SRAM

Embedded Memory (Kbit)

117

Total Number of Block RAM

IP Core

Viterbi Compiler, Low-Speed/Hybrid Serial Decoder|V1
ColdFire|SpeedView Enabled JPEG Encoder (SVE-JPEG-E)|10
Gigabit Ethernet MAC|32/64-bit PCI-X bus Master/Target interface Core,
66/100/133Mhz

Provider Name

Altera/Freescale/CAST, Inc/MorethanIP/PLDA

Device Logic Units

4608

Number of Global Clocks

Device Number of DLLs/PLLs

JTAG Support

Yes

Maximum Supply Current (mA)

10(Typ)

Programmability

Reprogrammability Support

Number of Look-up Table Input

Copy Protection

In-System Programmability

Yes

Opr. Frequency (MHz)

402.58

Speed Grade

Differential I/O Standards

LVDS|PCI-X

Single-Ended I/O Standards

LVDS|PCI-X

Maximum I/O Performance

640Mbps

External Memory Interface

DDR SDRAM|QDR II+SRAM

Minimum Operating Supply Voltage (V)

1.15

Maximum Operating Supply Voltage (V)

1.25

I/O Voltage (V)

1.5|1.8|2.5|3.3

Minimum Operating Temperature (°C)

Maximum Operating Temperature (°C)

Supplier Temperature Grade

Commercial

Tradename

Cyclone

Intel / Altera EP2C5T144C8N's Datasheet

Intel / Altera EP2C5T144C8N's Category-FPGAs

Field Programmable Gate Arrays (FPGAs) are off-the-shelf integrated circuits. The "field programmable" feature empowers customers to reconfigure the hardware post - manufacturing to meet specific use - case demands. This is extremely beneficial as it allows for in - situ feature upgrades and bug fixes, especially crucial for remote deployments. Internally, FPGAs consist of configurable logic blocks (CLBs) and programmable interconnects. Designers can utilize these components to connect and configure the blocks, enabling the implementation of functions ranging from simple logic gates to highly complex operations. In fact, entire System - on - Chip (SoC) designs with multiple processes can be realized on a single FPGA device. The versatility of FPGAs is a major draw for developers. After the board is built, developers can test numerous variables. When changes are needed, new configuration files can be transferred to the device to enable new functionality. This flexibility enables Original Equipment Manufacturers (OEMs) to introduce systems earlier in the design process. FPGAs are also frequently used in commercial applications requiring parallel computing and having dynamic requirements, such as in telecoms and avionics. They are valuable in hardware prototyping, as they allow digital hardware designs to be verified without the high upfront cost of Application - Specific Integrated Circuit (ASIC) manufacture. Additionally, they can be used for hardware acceleration, where implementing parts of algorithms in custom hardware speeds up designs. In space avionics, radiation - hardened FPGAs in satellites can receive new configuration files to execute upgrades, install new features, or fix bugs even without physical access. They are also well - suited for neural networks, as their design topology can better fit and accelerate matrix multiplication.

Among the various FPGA offerings, the Intel / Altera EP2C5T144C8N stands out. It belongs to the Cyclone II series. This chip, released in 2007, uses 90 - nanometer technology. It has 5,136 logic units, which can be configured to perform a wide range of logical operations. With 262,144 storage units, it can store a significant amount of data. The 144 - pin package provides extensive connectivity options. Operating at a maximum frequency of 200MHz, it can handle high - speed data processing tasks. Its power supply voltage ranges from 1.2V to 3.3V, making it adaptable to different power sources. It is widely used in embedded systems, graphics and image processing, and audio - video codec applications, taking advantage of its low - power consumption, high - performance, and flexibility characteristics.

EP2C5T144C8N vs EP2C5F256C8N vs EP2C5F256I8N

Part Number	EP2C5T144C8N +BOM	EP2C5F256C8N +BOM	EP2C5F256I8N +BOM
Manufacturer	Intel	Intel	Intel
Package	TQFP-144	FBGA-256	FBGA-256
Description	4608 cells with a clock speed of 402.58MHz	The EP2C5F256C8N is a cutting-edge FPGA from the Cyclone® II Family, boasting 4608 cells and a clock speed of 402.58MHz	90nm Technology for EP2C5F256I8N FPGA with 256-pin FBGA package
Stock	7000	8505	9861
Series	Cyclone II EP2C5	Cyclone II EP2C5	Cyclone II EP2C5
Package / Case	TQFP-144	FBGA-256	FBGA-256
Product Category	FPGA - Field Programmable Gate Array	FPGA - Field Programmable Gate Array	FPGA - Field Programmable Gate Array
RoHS	Details	Details	Details
Number of Logic Elements	4608 LE	4608 LE	4608 LE
Adaptive Logic Modules - ALMs	288 ALM	288 ALM	288 ALM
Embedded Memory	117 kbit	117 kbit	117 kbit
Number of I/Os	89 I/O	158 I/O	158 I/O
Supply Voltage - Min	1.15 V	1.15 V	1.15 V
Supply Voltage - Max	1.25 V	1.25 V	1.25 V
Minimum Operating Temperature	0 C	0 C	- 40 C
Maximum Operating Temperature	+ 70 C	+ 70 C	+ 85 C
Mounting Style	SMD/SMT	SMD/SMT	SMD/SMT
Brand	Intel / Altera	Altera	Intel / Altera
Maximum Operating Frequency	260 MHz	260 MHz	260 MHz
Moisture Sensitive	Yes	Yes	Yes
Number of Logic Array Blocks - LABs	288 LAB	288 LAB	288 LAB
Operating Supply Voltage	1.15 V to 1.25 V	1.15 V to 1.25 V	1.15 V to 1.25 V
Product Type	FPGA - Field Programmable Gate Array	FPGA - Field Programmable Gate Array	FPGA - Field Programmable Gate Array
Factory Pack Quantity	60	90	90
Subcategory	Programmable Logic ICs	Programmable Logic ICs	Programmable Logic ICs
Total Memory	119808 bit	119808 bit	119808 bit
Tradename	Cyclone II	Cyclone II	Cyclone II
Part # Aliases	969720	969718	966841
Unit Weight	0.705479 oz	0.052911 oz	0.224263 oz
Product Status			Active
Programmable			Not Verified
Number of LABs/CLBs			288
Number of Logic Elements/Cells			4608
Total RAM Bits			119808
Number of I/O			158
Voltage - Supply			1.15V ~ 1.25V
Mounting Type			Surface Mount
Operating Temperature			-40°C ~ 100°C (TJ)
Supplier Device Package			256-FBGA (17x17)
Base Product Number			EP2C5

WlS Electronic has a vast inventory of Intel / Altera EP2C5T144C8N. We assure you that these are genuine and brand - new components procured directly from Intel / Altera. Should you need it, we are able to offer quality test reports for EP2C5T144C8N. If you wish to obtain a quotation, all you need to do is fill in the required quantity, your contact name, and your email address in the quick quotation form on the right - hand side. Our sales representatives are committed to getting in touch with you within 12 hours. You have the option to contact us online at any time. Additionally, you can send us an email at: SALES@WLSCHIP.COM.
