One of the key features of the PIC16F15323-I/ST is its support for PWMs, multiple communication protocols, a temperature sensor, and innovative memory management features like Memory Access Partition (MAP) and Device Information Area (DIA). These capabilities enable developers to implement complex functions with ease, while optimizing system performance and reducing overall power consumption. The availability of different pin counts, ranging from 8 to 48-pins, further enhances the product's flexibility, allowing it to be used in a variety of applications.
Microchip Technology PIC16F15323-I/ST's Features
Core and Memory Features：It has an enhanced mid - range 8 - bit CPU core with 48 instructions, 16 - level deep hardware stack, and multiple addressing modes. The device offers 3.5 KB Flash Program Memory and 256 Bytes Data SRAM. The Memory Access Partition (MAP) provides write protection and customizable partitions, while the Device Information Area (DIA) stores factory calibration values, enhancing temperature sensor accuracy.
Power - Related Features：Operating voltage ranges from 2.3V to 5.5V. It supports multiple power - saving modes like DOZE, IDLE, and SLEEP. In DOZE mode, the CPU core can run slower than the system clock; IDLE mode halts the CPU core while internal peripherals continue operating; SLEEP mode offers the lowest power consumption. Additionally, the device has features like Low - Current Power - on Reset (POR), Brown - out Reset (BOR), and Low - Power BOR (LPBOR) options.
Digital Peripherals：Equipped with four Configurable Logic Cells (CLC) for integrated combinational and sequential logic. It has a Complementary Waveform Generator (CWG) with features such as rising and falling edge dead - band control. Two Capture/Compare/PWM (CCP) modules are available, with 16 - bit resolution for capture/compare modes and 10 - bit resolution for PWM mode. There are also four 10 - bit PWMs and a Numerically Controlled Oscillator (NCO) for generating true linear frequency control. The device includes one EUSART compatible with RS - 232, RS - 485, and LIN, and its I/O pins have features like individually programmable pull - ups, slew rate control, and interrupt - on - change.
Analog Peripherals：Features a 10 - bit Analog - to - Digital Converter (ADC) with up to 43 external channels that can operate in Sleep mode. It has up to two comparators with software - selectable hysteresis and a 5 - bit Digital - to - Analog Converter (DAC) with rail - to - rail output. The voltage reference provides fixed output levels of 1.024V, 2.048V, and 4.096V, and there is a Zero - Cross Detect module for simplifying TRIAC control.
Oscillator and Clock Features：Has a flexible oscillator structure including a high - precision internal oscillator with a software - selectable frequency range up to 32 MHz, x2/x4 PLL with internal and external sources, and a low - power internal 31 kHz oscillator (LFINTOSC). It also supports external oscillator modes with crystal/resonator options up to 20 MHz and has a Fail - Safe Clock Monitor to ensure safe shutdown if the primary clock stops.
In the industrial control realm, its analog and digital peripherals play a crucial role. The 10 - bit ADC with numerous external channels and the comparators are useful for monitoring and controlling various analog signals, such as temperature, pressure, and voltage. For example, in a factory automation system, it can precisely measure sensor data and adjust the operation of machinery accordingly. The multiple PWMs are ideal for controlling motors, enabling smooth speed regulation.
In consumer electronics, its low - power features like DOZE, IDLE, and SLEEP modes are highly beneficial. These modes help in reducing power consumption, which is essential for battery - powered devices such as portable medical devices or wireless sensors. The integrated communication peripherals, such as EUSART, facilitate seamless data transfer between different components, allowing for features like remote control and data sharing.
In automotive applications, the device's ability to handle multiple tasks simultaneously is valuable. It can manage functions like engine control, where the accurate timing provided by the timers and the high - speed communication capabilities ensure efficient operation. The Zero - Cross Detect module can be used in power management systems to optimize the performance of electrical components.
Microcontrollers are the unsung heroes powering a vast array of modern devices, from simple household appliances to complex industrial machinery. These tiny integrated circuits pack a punch, combining a microprocessor core with essential peripherals like memory, input/output ports, and timers into a single chip. This integration makes them highly efficient, cost-effective, and space-saving, enabling developers to create innovative solutions with ease.
One of the key advantages of microcontrollers is their versatility. They can be programmed to perform a wide variety of tasks, such as controlling motors, sensing environmental conditions, processing data, and communicating with other devices. This flexibility allows engineers to tailor microcontrollers to the specific requirements of their applications, resulting in optimized performance and functionality.
Another notable feature of microcontrollers is their low power consumption. With the increasing demand for energy-efficient devices, microcontrollers play a crucial role in reducing power consumption without sacrificing performance. Many microcontrollers offer power-saving modes that can be enabled when the device is idle, further extending battery life and reducing energy costs.
Among the numerous microcontroller options available in the market, the Microchip Technology PIC16F15323-I/ST stands out as a reliable and high-performing choice. This microcontroller is part of Microchip's popular PIC16 family and offers a range of features designed to meet the needs of various applications. With its 8-bit architecture, generous memory, and rich set of peripherals, the PIC16F15323-I/ST provides developers with the flexibility and performance required to bring their ideas to life. Whether it's a simple embedded system or a complex IoT application, the PIC16F15323-I/ST is a microcontroller that can be counted on.
PIC16F15323-I/SL alternative models:PIC16F15323-I/ST
WlS Electronic has a large inventory of Microchip Technology PIC16F15323-I/ST. We guarantee that they are original and brand - new parts purchased directly from Microchip Technology. We can provide quality test reports for PIC16F15323 - I/ST according to your requirements. To get a quotation, simply fill in the required quantity, contact name, and email address in the quick quotation form on the right - hand side. Our sales representatives will contact you within 12 hours. You can contact us online at any time or send us an email: SALES@WLSCHIP.COM.
